    0.5Kg-0.6Kg 581 681 Rotary Tiller Blades For Tractor Double Hole Blue Colorful

    Ask Lasest Price
    Brand Name : SS GOLD;SH SUPER;OEM
    Model Number : DF DRY/WET;SF DRY WET;581 681
    Certification : ISO9001:2008
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 100000SETS PER MONTH
    Delivery Time : Within 20 working days after deposit
    • Product Details
    • Company Profile

    0.5Kg-0.6Kg 581 681 Rotary Tiller Blades For Tractor Double Hole Blue Colorful

    0.5kg-0.6kg 581 681 power tiller blade for tractor double hole blue colorful packing


    Details

    Code No.PlateHole dia/disWorking heightWorking radiusWeight
    QB-R0125mm*10mm10mm50mm195mm0.4kg
    QB-R0225mm*10mm11/24mm52mm225mm0.5kg
    QB-R0330mm*10mm13mm45mm240mm0.65kg
    QB-R0430mm*10mm13mm50mm225mm0.48kg
    QB-R0525mm*7mm11mm50mm175mm0.30kg
    QB-R0630mm*10mm13mm55mm245mm0.55kg
    QB-R0725mm*10mm12mm50mm225mm0.5kg
    QB-R0825mm*10mm12/24mm56mm225mm0.5kg
    QB-R0930mm*10mm14mm52mm225mm0.5kg
    QB-R1030mm*10mm14mm55mm225mm0.5kg
    QB-R1124mm*8mm11mm34mm120mm0.2kg
    QB-R1230mm*10mm12.5mm45mm230mm0.68kg
    etc.
    Chemical Composition
    MaterialChemical compostion table
    C(%)Si(%)Mn(%)Cr(%)P(%)S(%)B(%)
    65MnO.62-0.700.17-0.370.90-1.20≤0.25≤0.015≤0.035
    60Si2Mn0.56-0.641.50-2.000.69-0.90≤0.35≤0.035≤0.035
    55SiMnB0.52-0.601.50-2.000.69-0.90≤0.35≤0.035≤0.035
    28SiMnB0.24-0.320.60-1.001.20-1.600.0140.0150.0005-0.0035
    30MnCrB50.26-0.34≤0.401.10-1.400.30-0.60≤0.025≤0.035
    SuP90.52-0.600.15-0.350.65-0.950.65-0.95≤0.030≤0.030

    We also can provide the follow Single cylinder diesel engine part product:

    Camshaft and Crankshaft; Plunger and delivery valve
    Cylinder block, Cylinder head, cylinder liner; Piston, Piston ring/Pin
    Cylinder head, Cylinder head bonnet/gasket/bolt/nut/wrench
    Connecting rod, Connecting rod bushing/ bearing/Bolt
    Valve, Valve spring/guide/seat /spring seat/collet/push rod/tappet /Needle valve spindle
    Rocker arm, Rocker arm/bolt /seat /seat stub /seat shaft,
    Fuel injection, Fuel injection pump; Oil pump, Oil pump rotor
    Main bearing housing/alloy; Balancing shaft/gear; Starting shaft/gear/handle
    Air filter, Air filter element; Fuel filter, Fuel filter element
    Fuel tank, Fuel tank cap; Water tank, Water tank cap
    Intake and exhaust pipe, Intake and exhaust pipe gasket
    Dipsticks; Silencer; Gear, Bearing, Flywheel
